Freeze Dryer Labfreez FD-12-MTP
FD-12 Freeze Dryer/lyophilizer is applicable for freezedrying test of laboratory samples and suitable for small amount of production.
- Description
- Specifications
Description
Freeze Dryer Labfreez FD-12-MTP
Characteristics :
- Microprocessor control & LCD touch display which can display drying curve, vacuum, condenser temp., run time, ambient temperature.
- Pre-freezing function for samples.
- Large refrigerating capacity and slight noise of DANFOSS(SECOP) compressor with CFC-FREE refrigerant.
- 304 stainless steel of condenser, table-top, racks & shelves to ensure corrosionresistant and easy to clean; shelves height adjustable.
- Transparent drying chamber is safe and easy to observe;
- Novel design, small size and easy operation;
- For water based samples, the -55°C condenser is the perfect choice with effective cost. For samples containing solvents or with low eutectic points, the -80 C dual cascade refrigeration condenser provides maximum performance (optional).
- For labs that needs quick turn-around, electric heating defrost is optional.
- Nitrogen inflation valve is available.
- It includes the following types: Normal type, Top-press type, multi-manifold T type and multi-manifold Top-press type to meet the various requirements.
- CE/ISO 9001 13485 14001 certificated.
| Model | FD-12-R | FD-12-MR | FD-12-TP | FD-12-MTP | FD-12-MT | |
| Dry chamber size (D*H) | Ф260 × 430mm | Ф260 × 465mm | Ф260 × 490mm | Ф260 × 540mm | / | |
| Total shelf area | 0.12 m2 | 0.12 m2 | 0.08 m2 | 0.08m2 | / | |
| Shelf size (mm) | Ф200*4pcs | Ф200 * 4pcs | Ф180 * 3pcs | Ф180 * 3pcs | / | |
| Shelf space height (mm) | 70 | 70 | 70 | 70 | / | |
| Vials load quantity | Ф12mm | 920 Pcs | 920 Pcs | 560 Pcs | 560 Pcs | 24 ports 430 × 480 mm (H*L) |
| Ф16mm | 480 Pcs | 480 Pcs | 285 Pcs | 285 Pcs | ||
| Ф22mm | 260 Pcs | 260 Pcs | 165 Pcs | 165 Pcs | ||
| Sample load capacity | 1.2L | 1.2L | 0.8L | 0.8L | / | |
| Condenser temp. | <-55°C (-80°C or even lower is optional) | |||||
| Cold trap size | Ф215 * 140 mm (Depth * Height) | |||||
| Ice remove capacity | 4 Kg/24h | |||||
| Cold type | Air-cooled | |||||
| Defrost type | Natural (Electric is optional) | |||||
| Ultimate Vacuum | < 5 Pa | |||||
| Vacuum pump | Included | |||||
| Pump rate | 2L/S | |||||
| Install Power | 970 W | |||||
| Voltage | 220v/50Hz or 110v/60Hz | |||||
| Dimensions | 460×556×(720+465)(mm) | |||||
| Weight | 120 kg | 135kg | 130kg | 140kg | 76 kg | |
