Hirayama – Autoclave HVA-85 (85 Liter)
- Description
- Specifications
Description
Hirayama – Autoclave HVA-85 (85 Liter)
Space-saving design with upward opening lid. Standard internal cooling fan for faster post-sterilization cooling. Double lid safety interlock prevents lid opening while cycle is in progress, pressurized chamber, or temperature exceeding 97°C. Sterilization mode sterilizes the agar, and then automatically keeps it warm to prevent it from hardening. One-touch lever to easily open and close the chamber lid. Gelatin melting mode that melts quickly and then automatically maintains it on liquid temperature, or for hot, faster start-up. The door closing sensor prevents the cycle from starting unless the door is closed properly. The in-process display shows the status and progress of the sterilization cycle.
| Product name | HICLAVE HVA series | ||
|---|---|---|---|
| Model | HVA-85 | HVA-110 | |
| Effective capacity | 85 L | 110 L | |
| Chamber size (φ x H mm) | 420 x 615 | 420 x 795 | |
| Operation mode | 3 modes (LIQUID with warming, LIQUID without warming, SOLID) | ||
| Temperature setting range |
Sterilization | 105℃ – 135℃ Variable | |
| Warming | 45℃ – 80℃ Variable | ||
| Lid lock | 97℃, fixed | ||
| Time setting range |
Sterilization | 1 min – 250 min, Remaining time is displayed | |
| Warming | 20 h, fixed | ||
| Cooling setting | 3 levels (Natural cooling, Pulse cooling, Forced cooling) | ||
| Maximum working pressure | 0.255MPa | ||
| Thermometer | Digital display 5℃ – 137℃ | ||
| Pressure gauge | Analog display 0MPa – 0.4MPa | ||
| Safety devices | Pressure safety valve, Over-current and earth leakage breaker, Low water cut off device | ||
| Alarms, error display | Low water heating, Temperature sensor wire disconnection, Over-temperature, Over-cool, Over-pressure, Abnormality in lid opening / closing lever lock |
||
| Outside dimensions (W x D x H mm) | 667 x 652 x 1011 | 667 x 652 x 1191 | |
| Weight (Approximately) | 78 kg | 85 kg | |
| Pressure vessel category | Small sized pressure vessel | ||
| Chamber material | Stainless steel (SUS304) | ||
| Power supply | AC220V / 230V / 240V, 50Hz / 60Hz (Specify voltage when ordering.) |
||
| Required power supply facility | 3.0kW | 4.0kW | |
| Power connection |  Ring terminal |
||
| Supplied accessories | Stainless steel wire basket, Bottom plate, Drainage hose, Exhaust hose, Exhaust bottle, Drain bottle, Caster stopper (2) | ||
※Specifications and appearance are subject to change without notice due to continuous product improvement.
