Precision Balance EW 620-3NM
The classic balance with robust tuning fork measuring system
Terima kasih atas ketertarikan Anda. Setelah melengkapi informasi berikut, PT Dzana Mitra Sentosa akan segera menghubungi Anda.
Dengan mengisi formulir ini, saya menyatakan bahwa saya telah membaca, memahami dan menyetujui informasi penting sebagai berikut : Saya setuju untuk memberikan data dan informasi di atas kepada PT Dzana Mitra Sentosa. Saya setuju PT Dzana Mitra Sentosa menghubungi saya untuk menawarkan produk melalui email atau melalui telepon. Saya memahami informasi di atas disampaikan hanya untuk keperluan penawaran produk dengan PT Dzana Mitra Sentosa sesuai dengan Kebijakan Privasi.
- Description
- TECHNICAL DATA
Description
Precision Balance EW 620-3NM
- Adjusting program CAL for quick setting of the balance accuracy using an external test weight at an additional price, see test weights
- Stable temperature behaviour
- Short stabilisation time
- Shock proof construction
- High corner load performance
- Capacity display: A bargraph display lights up to show how much of the weighing range is still available
- Totalising of pieces when counting
- Draught shield standard, weighing space W×D×H 158×130×78 mm
- Protective working cover included with delivery
Technical Data
| Weighing capacity [Max] | 620 g |
| Readability [d] | 0,001 g |
| Units | g, dwt, tl (Tw), tl (HK), ozt, tl (Singap, Malays), ct, mo, lb, oz, tol |
| Linearity | ± 0,003 g |
| Reproducibility | 0,001 g |
| Stabilization time | 2 s |
| USP Minimum weight of sample (k = 2, U = 0.1%) | 2 g |
| Interfaces | RS-232 standard |
| Adjustment options | Adjusting with external weight |
| Recommended adjusting weight | 500 g (E2) |
| Ambient temperature | 10 °C – 30 °C |
| Dimensions weighing surface (Ø) | 118 mm |
| Material draught shield | plastic |
| Material housing | plastic |
| Dimension housing (W×D×H) | 180×235×75 mm |
| Material weighing plate | stainless steel |
| Net weight approx. | 1,4 kg |
| Construction type of the scale | Single-range balance |
| GTIN/EAN number | 4045761028883 |
